Mode Description
portForwarding The Port Forwarding mode, where every cascaded device in the
chain shares the same IP address, with diverse port numbers
assigned.
Important: When enabling either cascading mode, you must make sure the other
cascading mode is disabled, or the preferred cascading mode may not be enabled
successfully.
• •
<option1> is one of the following options:
Option Description
true The selected cascading mode is enabled.
false The selected cascading mode is disabled.
▶
If Port Forwarding mode is enabled, you must configure two more settings to finish the
configuration:
On ALL cascaded devices, you must configure the 'role' setting one by one.
config:# network portForwarding role <option2>
On the primary device, you must configure the 'downstream interface' setting.
config:# network portForwarding
primaryUnitDownstreamInterface <option3>
Variables:
• •
<option2> is one of the following cascading roles:
Role
primary
expansion
• • <option3> is one of the following options:
Option Description
ETH1/ETH2 ETH1/ETH2 port is the port where the 1st expansion device is
connected.
Usb USB port is the port where the 1st expansion device is connected.
Setting Network Service Parameters
A network service command begins with network services.
Description
The device is a primary device.
The device is an expansion device.
