Step 1: Set up the ping monitoring for the target PDU
1) Choose Device Settings > Server Reachability.
2) Click
3) Ensure the "Enable ping monitoring for this server" checkbox is selected.
4) Enter the data shown below.
• • Enter the server's data.
Field
IP address/hostname
• • To make the PRO3X declare the accessibility of the monitored PDU every 15 seconds (3 pings * 5
seconds) when that PDU is accessible, enter the following data.
Field
Number of successful pings to enable feature
Wait time after successful ping
• • To make the PRO3X declare the inaccessibility of the monitored PDU when that PDU becomes
inaccessible for around 12 seconds (4 seconds * 3 pings), enter the following data.
Field
Wait time after unsuccessful ping
Number of consecutive unsuccessful pings for failure
• • To make the PRO3X stop pinging the target PDU for 60 seconds (1 minute) after the PDU
inaccessibility is declared, enter the following data. After 60 seconds, the PRO3X will re-ping the
target PDU,
Field
Wait time before resuming pinging after failure
• The "Number of consecutive failures before disabling feature (0 = unlimited)" can be set to any •
value you want.
5) Click Create.
▶
Step 2: Create an event rule to send SNMP notifications for the target PDU
1) Choose Device Settings > Event Rules.
2) Click
3) Select the Enabled checkbox to enable this new rule.
4) Configure the following.
276
.
Data entered
192.168.84.95
.
Data entered
3
5
Data entered
4
3
Data entered
60
