config:# sensor outlet 5 current upperCritical disable upperWarning enable
lowerWarning 1.0
Results:
• • The Upper Critical threshold of outlet 5 RMS current is disabled.
• •
The Upper Warning threshold of outlet 5 RMS current is enabled.
• •
The Lower Warning threshold of outlet 5 RMS current is set to 1.0A and enabled at the same time.

Showing Information

You can use the show commands to view current settings or the status of the PRO3X device or part of it,
such as the IP address, networking mode, firmware version, states or readings of internal or external
sensors, user profiles, and so on.
Some "show" commands have two formats: one with the parameter "details" and the other without.
The difference is that the command without the parameter "details" displays a shortened version of
information while the other displays in-depth information.
After typing a "show" command, press Enter to execute it.
Note: Depending on your login name, the # prompt may be replaced by the > prompt.

Network Configuration

This command shows all network configuration and all network interfaces' information, such as the IP
address, MAC address, the Ethernet interfaces' duplex mode, and the wireless interface's status/
settings.
# show network
IP Configuration
This command shows the IP settings shared by all network interfaces, such as DNS and routes.
Information shown will include both IPv4 and IPv6 configuration.
# show network ip common
To show the IP settings of a specific network interface, use the following command.
# show network ip interface <ETH>
Variables:
• •
<ETH> is one of the network interfaces: ETH1/ETH2, WIRELESS, or BRIDGE. Note that you must
choose/configure the bridge interface if your PRO3X is set to the bridging mode.
