Set the Y coordinate:
config:# actuator <n> ylabel "<coordinate>"
▶
Set the Z coordinate:
config:# actuator <n> zlabel "<z_label>"
▶
Modify the actuator's description:
config:# actuator <n> description "<description>"
Variables:
• •
<n> is the ID number assigned to the actuator. The ID number can be found using the web interface
or CLI. It is an integer starting at 1.
• •
<name> is a string comprising up to 64 ASCII printable characters. The <name> variable must be
enclosed in quotes when it contains spaces.
• •
<coordinate> is a string comprising up to 24 ASCII printable characters, and it must be enclosed in
quotes.
• •
There are two types of values for the <z_label> variable, depending on the Z coordinate format you
set:
Type Description
Free form <coordinate> is a string comprising up to 24 ASCII printable
characters, and it must be enclosed in quotes.
Rack units <coordinate> is an integer number in rack units.
• •
<description> is a string comprising up to 64 ASCII printable characters, and it must be enclosed in
quotes when it contains spaces.
Example - Actuator Naming
The following command assigns the name "Door lock of cabinet 3" to the actuator whose ID number is
9.
config:# actuator 9 name "Door lock of cabinet 3"
