Variables:
• •
<n> is the number of the outlet that you want to configure.
• •
<option> is one of the options: off, on, lastKnownState and pduDefined.
Option Description
off Turn off the outlet.
on Turn on the outlet.
lastKnownState Restore the outlet to the state prior to last PDU power down.
pduDefined PDU-defined setting.
Note: Setting the outlet's default state to an option other than pduDefined overrides the PDU-defined
default state on that outlet.
Setting an Outlet's Cycling Power-Off Period
This section applies to outlet-switching capable models only.
This command determines the power-off period of the power cycling operation for a specific outlet.
config:# outlet <n> cyclingPowerOffPeriod <timing>
Variables:
• •
<n> is the number of the outlet that you want to configure.
• •
<timing> is the time of the cycling power-off period in seconds, which is an integer between 0 and
3600, or pduDefined for following the PDU-defined timing.
Note: This setting overrides the PDU-defined cycling power-off period on a particular outlet.
Example - Outlet Naming
The following command assigns the name "Win XP" to outlet 8.
config:# outlet 8 name "Win XP"

Outlet Group Configuration Commands

An outlet group configuration command begins with outletgroup. Such a command allows you to
configure or operate an outlet group.
