LEGRAND Server Technology PRO3X User Manual page 247

[USERNAME] logged into the device on [TIMESTAMP]
translates to
Mary logged into the device on 2012-January-30 21:00
▶
Operation:
1) Choose Device Settings > Event Rules >
2) Select 'Send SMS message' from the Action list.
3) In the 'Recipient phone number' field, specify the phone number of the recipient.
4) Select the 'Use custom log message' checkbox, and then create a custom message in the provided
text box.
• To automatically insert message placeholders, open the Custom Log Message Help section. Search •
for placeholders and click to include them in your message.
5) Click Create.
Send Snapshots via Email
This option notifies one or multiple persons for the selected events by emailing snapshots or videos
captured by a connected Logitech
▶
Operation:
1) Choose Device Settings > Event Rules >
2) Select 'Send snapshots via email' from the Action list.
3) In the 'Recipient email addresses' field, specify the email address(es) of the recipient(s). Use a
comma to separate multiple email addresses.
4) By default, the SMTP server specified on the SMTP Server page will be the SMTP server for
performing this action.
To use a different SMTP server, select the 'Use custom SMTP server' checkbox. The fields for
customized SMTP settings appear.
5) Select the webcam that is capturing the images you want sent in the email.
6) Adjust the values of the following:
• Number of snapshots - the number of snapshots to be taken when the event occurs. For example, •
you can specify 10 images be taken once the event triggers the action.
• • Snapshots per mail - the number of snapshots to be sent at one time in the email.
• Time before first snapshot - the amount of time in seconds between when the event is triggered •
and the webcam begins taking snapshots.
• Time between snapshots - the amount of time in seconds between when each snapshot is taken. •
7) If needed, you can customize the subject and messages sent via this email.
®
webcam.
.
.
247
