Server Status Checking or Power Control
Not all models supports the shutdown and power control features via the Server Reachability page.
After adding IT equipment for monitoring, all IT devices are listed on the Server Reachability page.
In the beginning, the status of the added IT equipment shows "Waiting for reliable connection," which
means the requested number of consecutive successful or unsuccessful pings has not reached before
PRO3X can declare that the monitored device is reachable or unreachable.
To check the server monitoring states and results:
1) The column labeled "Ping Enabled" indicates whether the monitoring for the corresponding IT
device is activated or not.
2) The column labeled "Status" indicates the accessibility of monitored equipment.
Status
Reachable
Unreachable
Waiting for reliable
connection
3) If your model supports outlet switching, one more column displays -- Power Control.
Power control
Description
status
(disabled)
Power control is not enabled for the monitored equipment.
Server power is
The outlet or outlet group associated with the monitored
on
equipment is being powered on.
Server power is
The outlet or all outlets of the outlet group associated with the
off
monitored equipment are being powered off.
274
Description
The monitored equipment is accessible.
The monitored equipment is inaccessible.
The connection between the device and the monitored
equipment is not reliably established yet.
In the scenario where an 'outlet group' is associated with the
equipment, the message 'Server power is on' is shown as long
as one of the outlets in the outlet group remains powered on.
