Set the assertion timeout for an overcurrent protector:
config:# sensor ocp <n> <sensor type> assertionTimeout <as_value>
▶
Set the residual current sensor parameters
config:# sensor ocp <n> residualCurrent|residualDCCurrent
upperCritical|upperWarning|lowerWarning|lowerCritical|
hysteresis|assertionTimeout <as_value>
Variables:
• • <n> is the number of the overcurrent protector that you want to configure.
• •
<sensor type> is one of the following sensor types:
Sensor type
current
Note: If the requested sensor type is not supported, the "Sensor is not available" message is
displayed.
• •
<option> is one of the options: enable, disable or a numeric value.
Option Description
enable Enables the specified threshold for the overcurrent protector
sensor.
disable Disables the specified threshold for the overcurrent protector
sensor.
A numeric value Sets a value for the specified threshold of the overcurrent
protector sensor and enables this threshold at the same time.
• •
<hy_value> is a numeric value that is assigned to the hysteresis for the specified overcurrent
protector sensor.
• •
<as_value> is a number in samples that is assigned to the assertion timeout for the specified
overcurrent protector sensor.
Commands for Environmental Sensors
A sensor threshold configuration command for environmental sensors begins with sensor
externalsensor.
You can configure various environmental sensor threshold settings at a time by combining multiple
commands.
Description
Current sensor
