1) Click > Threshold Bulk Setup.
2) Select one or multiple OCPs.
3) Click Edit Thresholds.
4) Make changes as needed.
• • To enable any threshold, select the corresponding checkbox.
• Type a new value in the accompanying text box. •
5) Click Save.

Individual OCP Pages

An OCP's data/setup page is opened after clicking any OCP's name on the OCPs or Dashboard page.
▶
General OCP information:
Field Description
Label This OCP's physical number.
• •
• •
Status open or closed.
If a trip cause has been detected, the details are linked
here with the Open status.
Type This OCP's type.
Rating This OCP's rated current.
Lines Lines associated with this OCP.
Protected Outlets associated with this OCP.
outlets
128
C1, C2, C3...
BR1, BR2, BR3...
