once the respective OCP is closed, the outlet is not turned on again
• • outlet state shows as 'suspended' in the web interface and the CLI
• •
warnings are shown when you attempt to turn on a suspended outlet
• •
for supported models, a different outlet LED color is shown

Time Units

If you choose to type a new value in the time-related fields, such as the "Idle timeout period" field, you
must add a time unit after the numeric value. For example, you can type '15 s' for 15 seconds.
Note that different fields have different range of valid values.
▶
Time units:
Unit Time
ms millisecond(s)
s second(s)
min minute(s)
h hour(s)
d day(s)

Setting Thresholds for Total Active Energy or Power

This section applies only to multi‑inlet models, including in‑line monitors.
Thresholds for total active energy and total active power are disabled by default. You can enable and set
them so that you are alerted when the total active energy or total active power hits a certain level.
For a regular PRO4X model with multiple inlets:
• •
Total active energy = sum of all inlets' active energy values
• •
Total active power = sum of all inlets' active power values
For an in‑line monitor with multiple inlets/outlets:
• • Total active energy = sum of all outlets' active energy values
• •
Total active power = sum of all outlets' active power values
▶
To configure thresholds for total active energy and/or power:
1) Click PDU.
2) Click the Thresholds title bar at the bottom of the page to display thresholds.
128
