http://192.168.84.77:50102/
• •
To access Expansion 2 via SSH, the command is:
ssh -p 50202 192.168.84.77
Adding, Removing or Swapping Cascaded Devices
Change a device's cascading mode first before adding that device to a cascading chain, or before
disconnecting that device from the chain.
If you only want to change the cascading mode of an existing chain, or swap the primary and expansion
device, always start from the expansion device.
Note: If the following procedures are not followed, a networking issue occurs. When a networking issue
occurs, check the cascading connection and/or software settings of all devices in the chain.
▶
To add a device to an existing chain:
1) Connect the device you will cascade to the LAN and find its IP address, or connect it to a computer.
2) Log in to this device and set its cascading mode to be the same as the existing chain's cascading
mode.
3) (Optional) If this device will function as an expansion device, disconnect it from the LAN after
configuring the cascading mode.
4) Connect this device to the chain, using either a USB or Ethernet cable.
▶
To remove a device from the chain:
1) Log in to the desired cascaded device, and change its cascading mode to None.
Exception: If you are going to connect the removed device to another cascading chain, set its cascading
mode to be the same as the mode of another chain.
2) Now disconnect it from the cascading chain.
▶
To swap the primary and expansion device:
• •
In the Bridging mode, you can swap the primary and expansion devices by disconnecting ALL
cascading cables from them, and then reconnecting cascading cables. No changes to software
settings are required.
• •
In the Port Forwarding mode, you must follow the procedure below:
