Use the front panel display to view information and even administer features on supported models. It
consists of:
• •
LCD display
• • Four control buttons
Zero U models automatically adjust the orientation of the content shown after detecting the direction
of installation. You can also manually change the orientation. 1U and 2U models do NOT adjust the
content's orientation.
Note: All front panel display images in the User Guide are for Zero U models with the LCD front panel
display. Displays may differ slightly by model and on 1U and 2U models.

Automatic and Manual Modes

After powering on or resetting, the front panel display first shows some dots, then logo and finally
enters the automatic mode.
▶
Automatic mode without alerts available:
In this mode, the display cycles through information as long as there are no alerts.
▶
Manual mode:
To view more information or control outlets, enter manual mode.
Press or
To return to the automatic mode, press
▶
Alerts:
• • In the automatic mode, when an alert occurs, the display stops cycling through information, and
warns you by showing the alerts notice in a yellow or red background.
To enter the manual mode, press
• •
In the manual mode, both the top and bottom bars will turn yellow or red to indicate the presence
of any alert.

Control Buttons

Use the control buttons to navigate to the menu in the manual mode.
to enter the manual mode, where the Main Menu is first displayed.
until you return to the main display.
.
