Outlet switching -- available on outlet-switching capable models only.
• • Actuator control -- available on all models.
• •
Internal beeper's mute function -- available on all models
• •
Default front panel mode setup -- available on all models, except for the PX3-3000 series, which
does NOT provide inlet sensor information.
• •
RCM self-test -- available on those models which support residual current monitoring.
▶
To configure the front panel settings:
1) Choose Device Settings > Front Panel.
2) Configure the following:
• • To configure the default view of the LCD display, select one mode below.
Note: The default view is shown in the automatic mode.
Mode
Automatic mode The LCD display cycles through both the inlet and overcurrent
Inlet overview
• • To enable the front panel outlet-switching function, select the 'Outlet switching' checkbox.
• • To enable the front panel actuator-control function, select the 'Peripheral actuator control'
checkbox.
• • The built-in beeper's mute control function is enabled per default. To disable it, deselect the 'Mute
beeper' checkbox.
• • By default the front panel RCM self-test function, if available, is enabled.
3) Click Save.
If the 'Mute beeper' feature is enabled, you can operate the front panel to mute it whenever it
beeps.
Or you can turn on or off outlets/actuators by operating the front panel.

Configuring the Serial Port

You can change the bit rate of the serial port labeled CONSOLE / MODEM that is present on some
models. The default bit rate for console and modem operation is 115200 bps.
The following devices are supported via the serial interface:
• •
A computer for console management.
• • A Raritan KVM product.
• •
An analog modem for remote dial-in and access to the CLI.
• •
A GSM modem for sending out SMS messages to a cellular phone.
332
Data entered
protector information. This is the default.
Overcurrent protector information is available only when your
PRO4X has overcurrent protectors.
The LCD display cycles through the inlet information only.
