Notes About the Index Variables:
Access to the indicated variables (V500 to V519) is direct.
Via a variable number that is higher by 20 allows access to the same
variables, but also to the contents of the indicated target variable.
Displayed Index Variable
500 to 507
508
509
510 to 517
518
519
520
527
528
529
530
537
538
539
Fig. 10-21: Determining the Target Variable by Accessing the Index Variable
Interface
Number of the Target Variable
500 to 507
508
509
510 ... 517
518
519
<V500> + <V508> * <V509>
<V507> + <V508> * <V509>
508
509
<V510> + <V508> * <V509>
<V517> + <V508> * <V509>
518
519
