Data Display - Bosch Rexroth OptiFeed-FS EcoDrive 03 FLP04VRS Functional Description

14-20
Display

Data Display

Display Variable
The contents of the programmed variable are written to the display
cyclically.
The contents of all variables can be displayed.
The number of places before and after the decimal can be designated.
N0500 TXT 0 1-0-2-00-100-183
Display of the Actual Position with Places Before the Decimal
Parameter Description
1 Assignment: Displays
0 0 = Display Variable
2 Display Line
00 Display Position
100 Variable Number
183
0 = Without operational sign
1xx
1 = With operational sign
x8x Number of Places Before Decimal
Number of Places After Decimal
xx3
Fig. 14-8: Variable Display
Display: Actual Position
TXT 0
Display Markers
N0500 TXT 0 1-1-2-00-M2.00.0
Parameter Description
1 Assignment: Displays
1 Display Marker Bit
2 Line
00 Position
M2.02.0 Complete Identifier
M = Marker
I = Input
Q = Output
Fig. 14-9: Marker Display
ECODRIVE03-FL*-04VRS
1-0-3-08-100-183
V100 = Actual Value, Axis1
DOK-ECODR3-FL*-04VRS**-FK01-EN-P
min. max.
-- --
-- --
1 6(7)
00 21
000 999
-- --
0 1
1 8
0 6
min. max.
-- --
-- --
1 6(7)
00 21
000 999
