ECODRIVE03-FL*-04VRS
4
General Instructions for Start-Up
4.1
Explanation of Terms
Communication
DOK-ECODR3-FL*-04VRS**-FK01-EN-P
So that the terms used in this document will be better understood, some
explanations are provided below.
Display
The 2-digit, 7-segment H1 display on the programming module indicates
the current status of the unit. Distinctions are made between:
• operating modes
• warnings
• errors
Errors can be acknowledged using the S1 key located below the display
on the programming module.
Serial Interface
Parameters and programs must be entered into the control in order for it
to conform to the system-specific requirements. This input is handled
exclusively via the serial interface (X2).
Rexroth has two options available:
• PC programming using MotionManager
• BTV04 display unit with FWA-BTV04*-ELC firmware
Fieldbus
The following can be transmitted via the fieldbus:
• cyclic I/O
• variables
S1 Key on Programming Module
The S1 key and the address switch located below it can be used to
control various basic settings.
The subsequent function is enabled by pressing the S1 key with the
address set to 00. The function enable signal is present for 20 seconds.
This is indicated by "Ad" on the display.
number and confirming it with the S1 key, the display disappears if the
function was completed.
Note:
When the basic parameters are set using switch settings 98
and 99, parameters that were previously set are overwritten.
Switch settings 98 and 99 only accepted in parameter mode.
The "temporarily" set interface parameters are reset to the parameter
values (B001/B002/B009/B010) after an error is cleared or after exiting
Parameter Mode.
General Instructions for Start-Up
After selecting the function
4-1
