9-6
Parameters
A101 Feed Constant
A102 Gearing
0100.0000
Feed Constant in IU
Note:
This is where the IU is defined
IU = Input Unit
This parameter describes the conversion from rotary to linear motion. It is
defined as the linear displacement of the load during one revolution of the
gear output shaft.
Input min.:
0.1000
Input max.:
5000.0000
0001 0001
Output Revolutions of the Load Gear
Input Revolutions of the Load Gear
A mechanical gear is often employed between the motor and the load.
The gear ratio is defined as:
Input
i =
Output
Fig. 9-2:
Gear Ratio
See also functional description for: "Gear Ratio" and "Modulo Function"
Example:
Five turns of the motor shaft equal two turns of the output shaft.
⇒
Input Revolutions: 5
Output Revolutions: 2
Input min.:
1
Input max.:
9999
ECODRIVE03-FL*-04VRS
IU
IU
Re
volutions
of
Load
Gear
Re
volutions
of
Load
DOK-ECODR3-FL*-04VRS**-FK01-EN-P
Gear
