9-62
Parameters

CM04 Number of Pole Pairs/Pole Pair Distance

CM05 Torque/Force Constant

0003
Number of Pole Pairs (rotary motor)
0750
Pole Pair Distance (linear motor)
Input is in 0,1 mm
For rotary motors, the number of pole pairs per motor revolution is
indicated here.
For linear motors, the length of a pole pair is to be entered here. In
motors with motor feedback memory, e.g., MKD motors, this value is
stored in memory and need not be specified.
(See also functional description for: "Motor feedback memory")
000.20
[Nm/A]
The torque/force constant indicates how much torque or force the motor
delivers at a certain effective current. For synchronous motors, this value
depends entirely on the design of the motor.
In asynchronous motors, this value is valid as long as the motor is not
operated in the field-weakening range.
For MHD, MKD and MKE motors, this value is stored in the feedback
memory and cannot be changed.
Input min.: 0,01
Input max.: 655,35 Nm/A
ECODRIVE03-FL*-04VRS
Nm/A
DOK-ECODR3-FL*-04VRS**-FK01-EN-P
