ECODRIVE03-FL*-04VRS
Variable Value Editable
DOK-ECODR3-FL*-04VRS**-FK01-EN-P
N0500 TXT 0 2-0-2-00-600-183
Parameter
Description
2
Assignment: Variable Contents
0
Reserved
2
Line
00
Position
600
Variable Number
183
Format
0 = Without operational sign
1xx
1 = With operational sign
x8x
Number of Places Before Decimal
Number of Places After Decimal
xx3
Fig. 14-10: Variable Value Editable
The contents of the programmed variable are written to the display
cyclically.
The current input position is shown as a negative value: To change the
value, it is possible to place the cursor in the field. Edited values are
shown in italics and are then no longer updated. By pressing OK, the
value is transferred and by pressing ESC, the old value is reestablished.
Display and Edit Parts of a Variable
The entire variable format : +00000000.000000
Depending on the format indicated, part of the variable value can be
displayed and edited. The invisible locations for the variables are not
changed and therefore remain intact.
Example:
V600 = + 00010000.000111
Display:
Change:
V600 = + 00010022.222111
Example: Display and Editing of Three Variables
TXT
0
TXT
0
TXT
0
0000.000
Format: 043
0022.222
2-0-4-10-600-043
2-0-5-15-601-030
2-0-6-14-602-040
14-21
Display
min.
max.
--
--
0
0
1
6(7)
00
21
000
999
--
--
0
1
1
8
0
3
