ECODRIVE03-FL*-04VRS

C007 Feed Constant 2

C008 Reserved

C009 Homing Configuration

DOK-ECODR3-FL*-04VRS**-FK01-EN-P
0500.0000
Feed Constant in IU
Encoder 2 is used as an optional encoder, measuring wheel axis or
master axis.
This parameter is read out only with rotary encoders.
This parameter describes the conversion from rotary to linear motion. It is
defined as the linear displacement of the load during one revolution of the
measuring wheel encoder shaft.
Input min.: 0.1000
Input max.: 5000.0000
1 0 0 10 20
Homing Acceleration in % of amax (A108)
Homing Velocity in % of Vmax (A106)
Reference Mark Measurement:
Home Switch, Evaluate:
Homing Direction
IU
IU
0 = yes
1 = no
0 = yes
1 = no
0 = positive
1 = negative
9-47
