ECODRIVE03-FL*-04VRS
Firmware Update in BTV04/05
DOK-ECODR3-FL*-04VRS**-FK01-EN-P
Serial transmission to X3 takes place via the RS 232 port.
The communications parameters of the DOLFI program must be set as
follows:
Options Å Com-Port
Options Å Address
Caution: The BTV04*-DOL-01Vxx module must never be overwritten.
Setup Menu in the BTV
Enter the Setup Menu by
• pressing the F2 key while the BTV is in the initialization phase.
• OR by pressing Shift + F6
Enter the Setup Menu for Port 2 by pressing F1 (Serial Port Parameter)
and then F3 (Serial Port 2)
Set to
Address:
3
Baud Rate:
9600
Parity:
off
Protocol:
ASCII +SIS
Answer Delay: 1 ... 4
Timeout (ms): 400
Retry:
2
Group No.:
0
Max Unit:
0
Once these data are set, exit this input level by pressing ESC. These data
are saved by pressing F3 (Save Values and Reboot).
General Instructions for Start-Up
Connect baud rate
Download baud rate
Receiver
4-13
9600
38400
03
