ECODRIVE03-FL*-04VRS
PLC Program (Logic Task)
DOK-ECODR3-FL*-04VRS**-FK01-EN-P
M a n u a l
P L C - P R O G R A M
0 0 0 0
>0 0 0 1
0 0 0 2
Any input or changes to the program can only be made in Parameter
Mode.
The instruction numbers of the logic task can be directly entered or
scrolled using the cursor keys or the page keys.
The definitions are input using the alphanumeric keypad. For inputting
letters, the cursor moves to the next space as soon as the Shift key is
released. After editing the text, it is saved by pressing OK.
The required input format must be observed and it is tested when exiting
Parameter Mode.
Variable
M a n u a l
V 6 0 0 + 0 0 0 0 0 0 0 0 . 0 0 0 0 0 0
Selecting the variables can be done by directly inputting the variable
number or by scrolling using the Cursor keys.
The variables can also be edited in Automatic Mode. When calling up the
variable, the current value is read and displayed once. After editing the
contents, the new value is saved by pressing OK.
L D _ _ _ I 4 . 0 0 . 1
S T _ _ _ Q 2 . 0 1 . 1
E N D _ _
V A R I A B L E S
V 6 0 0 . . . V 9 9 9
14-11
Display
.
'H'
.
