ECODRIVE03-FL*-04VRS

Number of Lines

DOK-ECODR3-FL*-04VRS**-FK01-EN-P
In the default settings, the number of available lines is set to 6.
Using this command, the number can be increased to 7.
Note: With 7 preselected lines, for fields with an editing function, the
topmost pixels of the following line are overwritten!
Note: The number of lines should always be programmed first.
N0500 TXT 0 9-0-6
Parameter Description
9 Assignment:
0 Number of Lines
6 Number of Lines
Fig. 14-14: Number of Lines
14-23
Display
min max
-- --
0 0
6 7
