AA07 Measuring Wheel Mode

AA08 Various Functions

DOK-ECODR3-FL*-04VRS**-FK01-EN-P
Only in Automatic Mode
M2.02.3
"Activate Measuring Wheel" Input Bit
Input status = 0 : Control using motor encoder
Input status = 1 : Control using measuring wheel encoder
00.00.0 = no input programmed.
The measuring wheel is always active in Automatic Mode if
programmed in Parameter A100.
This parameter applies only if Measuring Wheel Mode has been
preselected in Parameter A100. The measuring wheel is always active in
Automatic Mode or can be disabled using the programmed input.
See also Parameter A117, Encoder Difference Monitoring.
M2.02.2 M2.02.3
Target Velocity Reached
As long as the roll moves the material at the pre-set velocity, the output bit
is set.
Parameter Mode active
This output indicates whether Parameter Mode is active.
If 00.00.0 is entered here, no output bit is selected.
M0 – M5; M8 ; I0 - I4 ; Q0 - Q3
Output Bit: Parameter Mode activated
Output Bit: Target velocity reached
The following is valid for both output bits:
M2, M3, M4
DKC21.3:
DKC 3.3:
EMD:
00.00.0 = Function Deactivated
9-21
Parameters
Q0.00.4-Q0.01.3
Q2.02.0-Q2.05.7
Q3.00.0-Q3.03.7
