N121 Switch 1 - Bosch Rexroth OptiFeed-FS EcoDrive 03 FLP04VRS Functional Description

9-68
Parameters

N121 Switch 1

1 270 090
Number of the Output Channel:
The number determines which output (Parameter N101 – N108) is
assigned to the PLS position.
On Position:
The point at which the output is turned on is defined by the on position. If
a hysteresis or lead time has been input in the corresponding parameters,
the on position is automatically calculated and adjusted.
Off Position:
The point at which the output is turned off is defined by the off position. If
a hysteresis or lead time has been input in the corresponding parameters,
the off position is automatically calculated and adjusted.
Note: Parameters N122 to N131 have the same function for
output channels 2 through 11.
Note: Parameters N111 to N131 can also be edited outside of
Parameter Mode.
ECODRIVE03-FL*-04VRS
Off Position
On Position
Number of the Output Channel (1 – 8)
DOK-ECODR3-FL*-04VRS**-FK01-EN-P
