Writing the User Program

SET - Set Variable Value

SET V600 = +
SET V600 = +12345678.123456
V601
or
Value
Operational Sign
Target Variable
Using this command, variables can be set from the program or copied
from another variable.
Valid inputs for 'Target Variable' and the corresponding limit values:
Variable Type Number
User-programmable V600 to V999
Indicated Basis V500 to V507
V510 to V517
Indicated Offset V508, V518
Factor
Indicated Index V509, V519
Fig. 6-29: Set Command: Valid Target Variable
Valid Inputs for 'Value':
Variable Type Value
User-programmable V600 to V999
Indicated Basis V500 to V507
V510 to V517
Indicated Offset Factor V508, V518
Indicated Index V509, V519
System V000 to V199
No Variable
Fig. 6-30: Set Command: Valid Target Variable
See also Section 6.6 – Variables.
The program proceeds to the next instruction following the time period of
one cycle.
ECODRIVE03-FL*-04VRS
Minimum Value Maximum Value
-99999999.999999 +99999999.999999
+600 +999
+0 +399
+0 +399
Access Comment
Direct
Indicated
Direct
Direct
Direct Only variable, according
to Fig. 6-1 and Fig. 6-2
Value
