12-50
Diagnostic Message Descriptions
P2
P3
P4
PL
UL
"Phase 2"
The control is in parameter mode and is checking the parameter data.
The power cannot be switched on. See also status message A002.
"Phase 3"
The control is transitioning from Phase 2 to Phase 4 (Manual or
Automatic Mode).
See also status message A003.
"Phase 4"
The control is in manual or automatic mode.
Normally, this display appears only very briefly.
"Basic Parameter Load" (Parameter Laden mit Basiswerten)
See also: F209 PL Load parameter default values
"Basic Load" (Urladen)
See also: F208 UL The motor type has changed
ECODRIVE03-FL*-04VRS
DOK-ECODR3-FL*-04VRS**-FK01-EN-P
