B002 Serial Interface Parameter 2

0 0 0 0 0 000
Response Delay Time in ms in RS485 Mode
1 = in the event of a fault, an error message is sent
automatically via the interface (in preparation).
0 = function deactivated
0 = SIS protocol
St 1 = ASCII protocol
2 = IDS-01 (SIS protocol in Parameter Mode)
3 = IDS-01 (ASCII protocol in Parameter Mode)
0 = no checksum error message
1 = checksum error message
write confirmation ( Y CR LF )
Checksum
0 = checksum validation on
1 = checksum validation off
For further details, see Section 10.2, `Serial Interface´
Response Delay:
In RS485 Mode, once the serial interface receives the last character of an
'LF' request (Line feed: ASCII Code 10), it immediately switches to Send
Mode. With various RS 485 PC driver cards, this leads to problems if the
cards are unable to switch to Receive Mode quickly enough.
The interface can delay the switch from Receive to Send Mode by a
defined amount of time (response delay).
The PC driver should be able to switch reliably from Send to Receive
Mode within this time limit.
ECODRIVE03-FL*-04VRS
000 = no delay (0 – 200)
0 = off
1 = on
