C002 Position Feedback 1 Type - Bosch Rexroth OptiFeed-FS EcoDrive 03 FLP04VRS Functional Description

9-44
Parameters

C002 Position Feedback 1 Type

00 0 0 0
Encoder Type
0 = rotary
1 = linear
Distance-Coded Measurement System:
0 = no distance-coded measurement system
1 = distance-coded reference marks
Direction:
0 = not inverted
1 = inverted
Absolute Measurement:
x0 = no absolute measurement possible
01 = absolute measurement possible and active
11 = Absolute measurement possible, but not active
This parameter is used to stipulate the most important properties of the
motor encoder (position encoder 1).
Remark:
In absolute measuring systems with memory, absolute measurement is
automatically set to x1.
For MHD, MKD and MKE motors, the encoder type, distance-coded
measuring system, and direction of movement are set by the drive and
are write-protected.
ECODRIVE03-FL*-04VRS
(Encoder is treated as absolute)
DOK-ECODR3-FL*-04VRS**-FK01-EN-P
