Replicate MAC address entries in the MAC address tables of the outer VLANs configured in
selective QinQ to the MAC address table of the default VLAN of the downlink port. This is for
forwarding uplink packets to the operator network.
Replicate MAC address entries in the MAC address table of the default VLAN of the downlink port
to the MAC address tables of all the outer VLANs configured in selective QinQ. This is for
forwarding packets from the operator network to the user networks.
VLAN 4093 is a special VLAN reserved for the IRF fabric feature. It can not serve as the destination
VLAN of the inter-VLAN MAC address replicating feature to receive MAC address entries from the other
VLANs.
Examples
# Enable the inter-VLAN MAC address replicating feature for Ethernet1/0/1 to replicate the MAC
address entries between the MAC address table of VLAN 4 (the default VLAN) and that of the outer
VLAN 10.
<Sysname> system-view
System View: return to User View with Ctrl+Z.
[Sysname] interface Ethernet 1/0/1
[Sysname-Ethernet1/0/1] mac-address-mapping 0 source-vlan 4 destination-vlan 10
[Sysname-Ethernet1/0/1] mac-address-mapping 1 source-vlan 10 destination-vlan 4

raw-vlan-id inbound

Syntax
raw-vlan-id inbound vlan-id-list
undo raw-vlan-id inbound { all | vlan-id-list }
View
QinQ view
Parameters
vlan-id-list: Lists of VLAN IDs. After receiving packets of these VLANs, the switch will encapsulate the
packets with the specified outer VLAN tag. You need to provide this argument in the form of { vlan-id [ to
vlan-id ] }&<1-10>, where the VLAN ID after the to keyword must be larger than or equal to the VLAN ID
before the to keyword and &<1-10> means that you can specify up to 10 VLANs/VLAN ranges for this
argument.
all: Removes all configurations of encapsulating an outer VLAN tag for specified inner VLANs in the
current view.
