VoiceFinder AP200 VoIP Residential Gateway (RGW) User's Guide Version 1.1
3.1.

Installation

3.1.1. Installation Procedure

Caution
Gateways or PCs connected to the Gateway.
AddPac Technology Co.,Ltd.
Plug in the console cable and configure the console terminal. (Refer to
3.1.2 for details.)
Connect the network to the desired port. Use RJ-45 cable with the LAN 1
port for connection with ADSL/Cable Modem or Router, and the RJ-45
cable with the LAN 0 port for connection with the HUB/Switch.
Log in the Gateway after the booting message on the console with the
root account. (Configuration is only possible when logged in with the root
account.)
Switch to Configuration Mode.
Assign an internet address to the desired port of usage. (Refer to Interface
Configuration.)
Configure the settings for the routing and VoIP related. (Refer to Chapter 4
and 5.)
Confirm the configured settings. (Refer to the Gateway administrative
commands.)
Save the settings on Flash Memory. (VoiceFinder AP200 immediately
operates under the new settings, but under certain network environments
rebooting is required.) (Refer to the following instructions for this part.)
Using commands such as Ping, Telnet, rlogin etc. check the status of other
