VoiceFinder AP200 VoIP Residential Gateway (RGW) User's Guide Version 1.1
Check the routing table to confirm if the Gateway is receiving the network
Use the Ping command to check other Gateways or PCs connection.
This completes the basic configuration procedure. For optional functions,

3.1.2. Console Connection

AddPac Technology Co.,Ltd.
information correctly.
refer to the related chapter
Connect the console port in the rear side of the Gateway with the
serial port of the prepared console terminal. (Refer to [Diagram 3.1
Console Cable Connection])
Use console cable provided in the package.
If using a PC for the console terminal, connect with the PC serial
port.
In order to use the PC as a console terminal, a communication
emulator application is required. Under normal circumstances, the
Hyper Terminal Program in Windows will suffice.
The console terminal should be configured as : 9,600 Baud, No Parity,
8Bits Data, One(1) Stop Bit. The VoiceFinder AP200 Gateway is set to
operate with the configurations above. Therefore, these settings are
required for communication between the Gateway and the console
terminal. (Refer to [Diagram 3-2 Hyper Terminal Configuration])
When configuring the Hyper Terminal, select the Hyper Terminal menus
in the following order:
Format and set each item.
The console port serves the purpose of configuring the VoiceFinder 1100
Gateway settings and checking its operating status.
File Configuration Connection Target
