VoiceFinder AP200 VoIP Residential Gateway (RGW) User's Guide Version 1.1
[ Figure 1-10 Back Side Panel Picture of VoiceFinder AP200 Model C VoIP RGW]

1.4.2. Network Interface

The Standard Model of AP200 VoIP Residential Gateway supports network
interfaces such as following lists.
2 Port LAN 0/1 10Mbps Ethernet Interface or 1port LAN0 and 4Port HUB
(LAN1)
1 Port RS232C Asynchronous Serial Interface
Above listed network interface can be used in various WAN/LAN network
environment for VoIP network integration. The Leased Line, xDSL, and Cable
networks are one of networks supported by AP200 VoIP RGW.
The next explains the network interfaces of AP200 VoIP Residential Gateway.
2-Ports 10Mbps Ethernet Interface for LAN 0/1 (2 x RJ45)
AP200 VoIP Residential Gateway supports the two 10Mbps Ethernet Interfaces.
Using these LAN Interfaces, various network application services are possible.
In case of AP200 Model A RGW, LAN1 Interface supports the 4-Port HUB 10Mbps
Ethernet Interface instead of 1-Port 10Mbps Ethernet Interface.
