VoiceFinder AP200 VoIP Residential Gateway (RGW) User's Guide Version 1.1
Configuration 7 – Calling under 2 network domain & Translate-outgoing call
Phone A
Voice Port 0/0
Destination 100
Phone C
Voice Port 0/0
Destination 300
Configuration & Description)
VoIP gateway A and B uses gatekeeper A, VoIP gateway C and D uses gatekeeper B.
There are 3 way following call path as follows.
1) Phone A to Phone B
Normal path.
Configuration
Refer to Configuration 2
2) Phone A to Phone C
VoIP gateway A and C is connected different gatekeeper each other. To connect
from phone A to phone C, gateway configuration should be setup static VoIP peer
to peer configuration for each other gateway and gatekeeper.
AP200-A Configuration
Gateway(config)# dial-p voice 200 VoIP
Gateway(config-dialpeer-VoIP-200)# destination-pattern ...
Gateway(config-dialpeer-VoIP-200)# session target ras
Gateway(config-dialpeer-VoIP-200)# dial-p voice 300 VoIP
Gateway(config-dialpeer-VoIP-300)# destination-pattern 3..
Gateway(config-dialpeer-VoIP-300)# session target 30.30.30.1
Gateway(config-dialpeer-VoIP-300)# exit
AddPac Technology Co.,Ltd.
AP200-A
10.10.10.1
AP200-C
30.30.30.1
Gatekeeper A
15.15.15.1
AP200-B
IP
Network
Gatekeeper B
35.35.35.1
Phone B
Voice Port 0/0
Destination 200
AP200-D
40.40.40.1
Phone D
Voice Port 0/0
Destination 200
