VoiceFinder AP200 VoIP Residential Gateway (RGW) User's Guide Version 1.1
[Example] SNMP Configuration and Usage
router# config
router(config)#
router(config)# snmp community 0.0.0.0 AddPac-Domain1 rw
☞
community-string is AddPac-Domain1.
router(config)# snmp host 131.23.1.1 AddPac-Domain v2c
Sends trap to the SNMP manager in "131.23.1.1" through SNMP v2c
protocol. At this time, the string is AddPac-Domain.
router(config)# snmp contact HongKilDong
indicating that the contact point is "HongKilDong" when trap occurs
router(config)# snmp location 9FlofBuilding4
message indicating that the installation location of the faulty
equipment is 9FlofBuilding4 when trap occurs
router(config)# snmp name Tac_Gateway1
indicating that the equipment name is Tac_Gateway1 when trap occurs
router(config)# snmp trap-authentication
accesses to an equipment with incorrect string, this commands
informs this to all SNMP Managers that are set in the Gateway.
router(config)# exit
router # show snmp
TRAP version
TYPE
------------------------------------------------------
community public
community private
community proxy
community AddPac-Domain1
host
contact
location : 9FlofBuilding4
name
system-shutdown : Not Implemented
trap-authentication : ENABLE
AddPac Technology Co.,Ltd.
☞ In this mode, SNMP Config is possible.
Exchanges information
Community-Name
AddPac-Domain
: HongKilDong
: Tac_Gateway1
with all
☞ Shows SNMP configuration status.
IP-Address
0.0.0.0
0.0.0.0
0.0.0.0
0.0.0.0
131.23.1.1
SNMP Managers
☞
Sends a message
☞ Sends a
☞
Sends a message
☞ If an SNMP Manager
Access Mode
read-only
read-write
read-write
read-write
SNMPv2c
-
whose
☞
112
-
