VoiceFinder AP200 VoIP Residential Gateway (RGW) User's Guide Version 1.1
[Example] Normal PPP Configuration and Usage
Router# configuration
Router(config)#interface
interface configuration mode.
Router(config-ether0.0)#
mode.
Router(config-ether0.0)# encapsulation pppoe
mode
Router(config-ether0.0)# ip address 131.12.1.1 255.255.0.0
☞ Sets the IP address as "131.12.1.1/16 bit mask
Router(config-ether0.0)# no shutdown
Router(config-ether0.0)# end
menu.
Router # show interface ethernet 0
serial interface 0
router# sh int e 0 0
AddPac Technology Co.,Ltd.
Interface : ether0.0
IP Address:211.238.72.221 Physical Inteface : Ethernet0
Network : 211.238.72.0
Administrator Status : UP
Network Type : Ethernet
Hardware Address : 00 02 a4 01 01 02
Ethernet0 is UP, Line protocol is UP
bandwidth : 10000 Kbit
operating mode
operating speed : 10 Mbps
last 1 minute data rate : tx 0 bps, rx 728 bps
input : 95305 packets, 8979269 bytes, 0 no buffers
error : 0 (0 length, 0 align, 0 short,
output: 3 packets, 288 bytes, 0 drop
error : 0 (0 underrun 0 deferred 0 collision)
☞ Enters into the configuration mode
ethernet
☞ Configuration is possible in this
☞ Exists from the configuration
: HALF-DUPLEX
0 crc, 0 overrun, 0 collision)
☞
0.0
Enters
☞ Sets the PPPoE
☞ Makes the interface up.
☞ Checks the status of the
Subnet Mask : 255.255.255.0
Operation Status : UP
MTU : 1500
into the
