VoiceFinder AP200 VoIP Residential Gateway (RGW) User's Guide Version 1.1

5.4.2. Voice Ports Configuration Task List and Steps

5.4.2.1.

Configuring FXS or FXO Voice Ports

Under most circumstances the default voice port values are adequate for both
FXO and FXS voice ports. If you need to change the default configuration for
these voice ports, perform the following tasks. The first two tasks are required;
the third task is optional.
1) Identify the voice port and enter the voice-port configuration mode.
2) Configure the following mandatory voice-port parameters.
3) Configure one or more of the following optional voice-port parameters.
Step
1
configure
2
voice-port
3
ring number
4
connection plar
5
description
6
7
output gain
AddPac Technology Co.,Ltd.
PLAR(Private Line Auto Ringdown) Connection Mode
Description
Ring Number
Input Gain
Output Gain
Command
location
number
string
string
input
gain
value
value
Description
Enter global configuration mode.
Identify the voice port you want to configure and
enter voice-port configuration mode.
(For FXO ports only) Specify the maximum number of
rings to be detected before answering a call.
(Optional) Specify the private line auto ringdown
(PLAR) connection, if this voice port is used for a PLAR
connection. The string value specifies the destination
telephone number.
(Optional) Attach descriptive text about this
voice port connection.
Specify (in decibels) the amount of gain to be inserted
at the receiver side of the interface. Acceptable
values are from -31 to 31.
Specify (in decibels) the amount of gain at the
transmit side of the interface.
179
-
-
