VoiceFinder AP200 VoIP Residential Gateway (RGW) User's Guide Version 1.1
5.7.5.6.1. Syntax
Keyword / Argument
2400
4800
7200
9600
12000
14400
disable
5.7.5.6.2. Default Value
14400 bps
5.7.5.6.3. Command Mode
Voice-Service Configuration Mode
5.7.5.6.4. Usage Guideline
Use the fax rate command to specify the fax transmission rate to all dial peers.
The values for this command apply only to the fax transmission speed and do
not affect the quality of the fax itself. The higher transmission speed values
(14,400 bps) provide a faster transmission speed but monopolize a significantly
large portion of the available bandwidth. The lower transmission speed values
(2400 bps) provide a slower transmission speed and use a relatively smaller
portion of the available bandwidth.
This command is meaningful only under T.38 Fax Relay.
disabled, T.38 fax relay does not operate. The fax relay made by the bypass
mode performs no operation in the gateway (as it does nothing for the fax
communication in the PSTN network) setting the rate does not mean anything.
Although T.38 is set as 14400 bps by this command, if two fax machines on both
sides operate at 9600, actual fax rate will be 9600 bps.
AddPac Technology Co.,Ltd.
Description
Specifies a fax transmission speed of 2400 bps.
Specifies a fax transmission speed of 4800 bps.
Specifies a fax transmission speed of 7200 bps.
Specifies a fax transmission speed of 9600 bps.
Specifies a fax transmission speed of 12,000 bits per
second (bps).
Specifies a fax transmission speed of 14,400 bps.
Disables Fax Relay transmission capability.
If the fax rate is
259
- -
