VoiceFinder AP200 VoIP Residential Gateway (RGW) User's Guide Version 1.1
[Example] Standard Access-List Configuration and Usage
AddPac Technology Co.,Ltd.
router(config)#
possible.
router (config)# access-l 1 deny 132.1.2.1 0.0.0.255
Denies all packets whose source addresses are "132.1.2.0/24bit."
router (config)# access-l 1 deny 150.1.3.2 0.0.0.223
Denies all packets whose source addresses are "150.1.3.0/21
bit."
router (config)# access-l 1 deny host 132.1.3.15
all packets incoming from the host whose source address is
"132.1.3.15."
router (config)# access-list 1 permit any
packets that do not satisfy conditions of the Access-List 1
above. * If this command line does not exist, all default packets
will be denied.
router (config)# interface Ethernet 0 0
configuration mode of the interface Ethernet 0.0.
router (config-ether0.0)# ip access-group 1 in
the Access-List 1 that has been set to all IP packets incoming
through the Ethernet 0.0 interface.
router # show access-list
Standard Access List (Index = 1)
1 : deny
2 : deny
3 : deny
4 : permit any
☞ In this mode, Access-list Config is
☞ Shows Access-List.
132.1.2.1 0.0.0.255
150.1.3.2 0.0.0.224
host 132.1.3.15
☞
☞
☞ Denies
☞ Permits all
☞ Enters into the
☞ applies
82
- -
