VoiceFinder AP200 VoIP Residential Gateway (RGW) User's Guide Version 1.1
[Example] Added Commands During CHAP Configuration (Client)
This is when the AP200 Gateway functions as a PPP CallIn client in the client side.
router (config)#interface ether0.0
configuration mode.
router (config- ether0.0)# encapsulation ppp
router (config- ether0.0)# ppp authentication CHAP
PPP authentication mode as CHAP for the ethernet0.0 interface.
router (config- ether0.0)# ppp CHAP hostname addpac
user name that was saved in the server during PPP CHAP connection
is different from the user name of the client Gateway, this command
sends the user name of the server side.
router (config- ether0.0)# ppp CHAP password router1
user name of the server side to check the password that the server
sends during PPP CHAP connection.
router (config- ether0.0)# ppp timeout 100
negotiation timeout value as 100 seconds.
router (config- ether0.0)# end
menu.
router # debug ppp packet
router #
router # ubdebug ppp packet
AddPac Technology Co.,Ltd.
Ethernet0.0 LCP: TIMEOUT
Ethernet0.0 LCP: O CONFREQ id=1
Ethernet0.0 BCP: TIMEOUT
Ethernet0.0 BCP: O CONFREQ id=1
☞ Enters into the interface
☞ Sets PPP connection
☞ Exists from the configuration
☞ Decodes PPP packets.
☞ Stops PPP packet debugging.
☞ Sets the PPP mode.
☞ Sets the
☞ If the
☞ Sets the
