VoiceFinder AP200 VoIP Residential Gateway (RGW) User's Guide Version 1.1
Step 3) set POTS Peer
Gateway(config)# dial-peer voice 100 pots
Gateway(config-dialpeer-pots-100)# port 0/0
Gateway(config-dialpeer-pots-100)# destination-pattern 100
Gateway(config-dialpeer-pots-100)# dial-peer voice 101 pots
Gateway(config-dialpeer-pots-101)# port 0/1
Gateway(config-dialpeer-pots-101)# destination-pattern 101
Gateway(config-dialpeer-pots-101)# exit
Step 4)set VoIP Peer
Gateway(config)# dial-peer voice 200 VoIP
Gateway(config-dialpeer-VoIP-200)# destination-pattern 2..
Gateway(config-dialpeer-VoIP-200)# session target 20.20.20.1
Gateway(config-dialpeer-VoIP-200)# dial-peer voice 300 VoIP
Gateway(config-dialpeer-VoIP-300)# destination-pattern 3..
Gateway(config-dialpeer-VoIP-300)# session target 30.30.30.1
Gateway(config-dialpeer-VoIP-300)# exit
Step 5) configuration Confirmation
Gateway(config)# show run
interface loopback0
ip address 127.0.0.1 255.0.0.0
!
interface ether0.0
ip address 10.10.10.1 255.255.255.0
!
interface serial0
ip address 100.100.100.1 255.255.255.252
Encapsulation HDLC
Operation is DOWN
!
!
Gateway(config)# sh route
Destination
---------------- --------------- ---------------- ------------ ---------
0.0.0.0
10.10.10.0
100.100.100.0
127.0.0.0
Gateway(config)# show dial-peer voice
POTS Peers :
Pots peer 100
dest-pattern = 100
port = 0/0 (0)
prefix =
register E.164 = yes
administrative status = up
Pots peer 101
dest-pattern = 101
port = 0/1 (1)
AddPac Technology Co.,Ltd.
Network-Mask Gateway
0.0.0.0
255.255.255.0 10.10.10.1
255.255.255.252 100.100.100.1
255.0.0.0 127.0.0.1
Interface Protocol
serial0 STATIC
ether0.0 DIRECT
serial0 DIRECT
loopback0 DIRECT
309
- -
