VoiceFinder AP200 VoIP Residential Gateway (RGW) User's Guide Version 1.1
Gateway(config-dialpeer-pots-100)# prefix
Description) Press 100200 at Phone B
Gateway A use No. "100"-> PBX connecting
2second delay
Gateway A dial up "0" to PBX
2 second delay
Gateway A dial up "200" to PBX
....
Call Scenario
1) Phone A To Phone B connection
Hang up Phone A.
-
Listen dial tone sound of PBX machine, and then press dial No. 802 in
-
connecting VoIP gateway A FXO port.
Listen dial tone sound of VoIP gateway A, and then press dial No. 200700 in
-
connecting part of VoIP gateway FXS voice port phone No. 200 and other
connecting part of PBX internal phone number 700. (2 stage)
Confirm RING sound.
-
Speak over the telephone.
-
Finish speaking out.
-
2) Phone B To Phone A connection
Hang up Phone B.
-
Listen dial tone sound of PBX B, and then press No. 8 in connecting VoIP
-
gateway FXO voice port.
Listen dial tone sound of VoIP gateway, and then press No. 100800 in
-
connecting part of VoIP gateway FXO voice port phone No. 100, and other
connecting part of PBX internal phone No. 800.
Confirm RING sound.
-
Speak over the telephone.
-
Finish speaking out.
-
AddPac Technology Co.,Ltd.
