VoiceFinder AP200 VoIP Residential Gateway (RGW) User's Guide Version 1.1
dtmfRelay = h245-alphanumeric
vad = yes
translation-outgoing called-number = -1
translation-outgoing calling-number = -1
description =
administrative status = up
VoIP peer 300
dest-pattern = 3..
session-target = 30.30.30.1
codec = default
codecClass = default
dtmfRelay = h245-alphanumeric
vad = yes
translation-outgoing called-number = -1
translation-outgoing calling-number = -1
description =
administrative status = up
Gateway(config)# voice class user 1
Gateway(config-vclass-user#1)# password 1234
Gateway(config-vclass-user#1)# max –digits 3
Gateway(config-vclass-user#1)# exit
Gateway(config)# voice class user 2
Gateway(config-vclass-user#2)# password 4567
Gateway(config-vclass-user#2)# max-digits 8
Gateway(config-vclass-user#2)# exit
Gateway(config)# voice class user 3
Gateway(config-vclass-user#2)# password 7890
Gateway(config-vclass-user#2)# max-digits 0
Gateway(config-vclass-user#2)# exit
call scenario)
1) Phone B to PSTN user A using user class 1
- Hang up Phone B.
- Press dial No. 100 of Phone B
- Listen shot dial tone, and then press password No. 1234 as user class 1
- Listen normal dial tone of PBX machine, and then press dial No. 800
- Speak over the telephone
- Finish speaking out.
2) Phone B to PSTN user A using user class 1
- Hang up Phone B
- Press dial No. 100 of Phone B FXO
- Listen shot dial tone, and then press password No. 1234 as user class 1
- Listen normal dial tone of PBX machine, and then press dial No. 9 for external
PSTN connection
- Listen dial tone, and then press dial No. 1234567 for PSTN call.
- Speak over the telephone
- Finish speaking out.
3) Phone B to PSTN user A using user class 2
- Hang up Phone B
- Press dial No. 100 of Phone B FXO voice port
- Listen shot dial tone, and then press password No. 4567 as user class 2.
