1.4.

Hardware Configuration and Network Interface

Information
This Chapter explains the external form and network interface module parts of
VoiceFinder AP200 VoIP Residential Gateway.

1.4.1. VoiceFinder AP200 Main Body

The external form of AP200 VoIP Residential Gateway is made by high degree
of strength ABS material. The front panel of this equipment is designed to
display the LED that indicates the system operation status. The back panel of
AP200 VoIP gateway is designed to support the flexible voice and LAN
interfaces including RS-232C serial port.
Front View of AP200
To check the system operation status easily, AP200 VoIP Residential Gateway
provides the Front panel LED. Following Figure 1-3 and 1-4 shows the Front Panel
external form and represents the explanation of each parts.
Figure 1-3 Front Panel Picture of VoiceFinder AP200 VoIP Residential Gateway
Table 1-1 shows the functional explanation about each LED of VoiceFinder
AP200 VoIP Residential Gateway.
