VoiceFinder AP200 VoIP Residential Gateway (RGW) User's Guide Version 1.1
STEP
1 Router# configure
2 Router(config)# voice service voip
3 Router(config-vservice-voip)# busyout
monitor
{gatekeeper | voip-interface}
5.3.12.2.

Busyout Action

User can set a specific action such as busyout tone or port-down in a specific
port when VoIP gateway is busyout. If busyout action is set as busyout tone and
situation that meet this condition is occurred, PBX does not call try in this port
because PBX recognizes as busy the state of Internal or external PBX line
connected to gateway port.
In this time, if PBX HUNT function is operated and a call is transferred to external
PSTN line via PBX when gateway port is busy, the perfect PSTN backup service is
possible.
STEP Commands
1 Router# configure
2 Router(config)# voice-port
slot-id/port-id
Router(config-voice-ports-0/0)#
3
busyout action
{none | tone | port-down}

Configuration Voice Ports

5.4.

5.4.1. Configuration Voice Ports on the AP200 Gateway

In general, voice port commands define the characteristics associated with a
particular voice port signaling type. Under most circumstances, the default
voice port command values are adequate to configure FXO and FXS ports to
transport voice data over your existing IP network.
AddPac Technology Co.,Ltd.
Commands Explanation
Enter into configuration setting mode.
Enter into Voice service voip mode
Gatekeeper : busyout setting applied
in gatekeeper.
Voip-interface: busyout setting applied
in voip-interface
Explanation
Enter into configuration setting mode
Enter into Voice-port configuration mode
None : no action
Tone : busy ton generation
Port-down : port down
178
- -
