VoiceFinder AP200 VoIP Residential Gateway (RGW) User's Guide Version 1.1

5.5.3. FAX Relay setting by Bypass

To set fax relay with G.711 PCM clean channel in addition of T.38 fax relay, use
following commands in Global Configuration Mode. To do fax relay in this
mode voice channel shall be opened with g711alaw or g711ulaw. So, codec
and codec-class setting of dial-peer needs to support g711alaw or g711ulaw
interface and counterpart needs to set in G.711 mode.
Step
1 Router(config)#voice service VoIP
2 Router(config-vservice-VoIP)#fax
protocol bypass
3 Router(config-vservice-VoIP)#exit
AddPac Technology Co.,Ltd.
Command Description
Converts into Voice Service Setting Mode
Sets Global default FAX protocol
Exits from
Mode and return to Global setting
Mode
Voice-Service Setting
183
- -
