AddPac VoiceFinder AP200 User Manual page 304

VoiceFinder AP200 VoIP Residential Gateway (RGW) User's Guide Version 1.1
Information
Users can see VoIP-related messages and call tracing through the console port.
This is default setting. However, if the user wishes to view call tracing through
the telnet terminal from a remote place, the user shall use "debug-port"
command (one of the global commands) from the remote terminal. Message
tracing operates either in the console or in the remote terminal wherever
"debug-port" command has been used. If the telnet terminal is terminated,
message tracing will automatically operate in the console. "No debug-port"
displays call tracing on the default display console.
Caution
Message tracing with using the debug command gives a high load to the router
so it is recommended not to use the debug command under normal conditions.
After tracing in the telnet terminal, do not exit the terminal without using "no
debug" or "undebug" command.
displayed in the console.
5.7.6.17.5. Examples
The following is an example of tracing an H.225 ASN.1 event for the system.
debug VoIP h225-asn1
The following is an example of switching an enabled H.245 ASN.1 Debugging
function off for the system.
undebug VoIP h245-asn1
AddPac Technology Co.,Ltd.
Otherwise, message tracing will be
304
- -
