VoiceFinder AP200 VoIP Residential Gateway (RGW) User's Guide Version 1.1
[Example] Added Commands During PAP Configuration (Server)
If the Gateway functions as a server, it means the AP200 Gateway functions as
the PPP authentication server.
Router(config)# user addpac password Router1 normal
the user name (addpac) and the password (Router1) with the normal
priority in the server.
Router (config)#interface Ethernet 0.0
interface configuration mode.
Router(config-ether0.0)# encapsulation pppoe
mode.
Router(config- ether0.0)# ppp authentication pap
authentication mode as PAP for the ethernet0.0 interface.
Router(config- ether0.0)# ip address 132.12.1.1 255.255.255.0
☞ Sets the IP address as "130.1.1.1" and the subnet mask as "24Bit."
Router(config-ether0.0)#
132.12.1.2
IP from this Router, this command enables the Router to provide default
address (130.1.1.2)to the other Router. (* If an IP address has been
set already in the other Router, the operator does not need to use
this command.)
Router(config- ether0.0)# ppp timeout 100
negotiation timeout value as 100 seconds.
Router(config-ether0.0)# end
menu.
Router # debug ppp packet
Router # ubdebug ppp packet
AddPac Technology Co.,Ltd.
☞ When the other Router receives the serial interface
Ethernet0 LCP: TIMEOUT
Ethernet0 LCP: O CONFREQ id=1
Ethernet0 BCP: TIMEOUT
Ethernet0 BCP: O CONFREQ id=1
Ethernet0 LCP: TIMEOUT
Ethernet0 LCP: O CONFREQ id=1
Ethernet0 BCP: TIMEOUT
Ethernet0 BCP: O CONFREQ id=1
☞ Enters into the
ppp peer default-ip
☞ Sets PPP connection
☞ Exists from the configuration
☞ Stops PPP packet debugging.
☞ Registers
☞ Sets the PPP
☞ Sets the PPP
address
