Appendix D Cable Specifications

This Appendix provides information about the Pinout specifications of the
following cables used with the VoiceFinder 1100 Gateway.
[ Console Port Signal and Pinout ]
In order to connect the Gateway console port with the Terminal Emulating PC,
the RJ-45 to DB9(Female DTE Connector) cable is used. The transferred signal
and Pinout specifications are enlisted in the following Table C-1 "Console Port
Signal and Pinout".
Gateway Console
AddPac Technology Co.,Ltd.
Console Port Signal and Pinout(RJ-45 to DB9)
Ethernet Cable Assemble(RJ-45 to RJ-45) Pinout
(DTE)
Signal
RTS
DTR
TxD
GND
GND
RxD
DSR
CTS
Table D-1 "Console Port Signal and Pinout" ]
RJ-45
RJ-45 Pin
1
2
3
4
5
6
7
8
Console Device
DB-9
DB-9 Pin
8
6
2
5
5
3
4
7
(PC)
Signal
CTS
DSR
RxD
GND
GND
TxD
DTR
RTS
