VoiceFinder AP200 VoIP Residential Gateway (RGW) User's Guide Version 1.1
5.7.2.6.2. Default Value
No Default Value
5.7.2.6.3. Command Mode
Global Configuration Mode
5.7.2.6.4. Usage Guideline
Use the num-exp global configuration command to define how to expand a
particular set of numbers (for example, an extension number) into a particular
destination pattern. With this command, you can map specific extensions and
expanded numbers together by explicitly defining each number, or you can
define extensions and expanded numbers using variables. You can also use this
command to convert seven-digit numbers to numbers containing less than
seven digits.
Number expansion is applied to the called party number of the inbound call.
The called party number of the inbound call from the voice port or the network
is translated by number expansion, and the dial peer is selected according to
the translation result.
If more than one number expansions match with the called party number of
the inbound call, the number expansion that matches most with the fixed
pattern of the expansion-number will be selected.
It is recommended to take cautions when using number expansion with
Caution
translation-incoming of the voice port or translate-VoIP-incoming of the
network at the same time. If translation of the number is clear enough, it is not
recommended to use two methods at the same time.
methods, translation-incoming or translate-VoIP-incoming will be applied first
and then number expansion will be applied.
Expansion-number can perform range expression.
AddPac Technology Co.,Ltd.
If a user uses two
(eg. [1-9]) Also, the
203
- -
